CRUSHER BUCKETS

BF120.4 S4

≥ 30 ≤ 45 Ton

Ideal for large projects

The BF120.4 crusher bucket has been created to satisfy specific requirements of crushing in quarries, landfills and for all operations regarding the recycling of aggregates.

It is a versatile and powerful machine which, in the space of just a few years, has established a strong presence in the sector of crushing in large-scale urban and non-urban sites.

TECHNICAL FEATURES

MODEL BF120.4
WEIGHT 4,80 Ton
LOAD CAPACITY 1,30 m³
PRESSURE > 220 bar
OIL FLOW > 190 < 260 L/min
MOUTH OPENING WIDTH 1205 mm
MOUTH OPENING HEIGHT 540 mm

The hydraulic flow and pressure must both meet the required parameters.
