SORTING GRAPPLES

MB-G1200 S4

≥ 18 ≤ 30 Ton

Great performance

Designed for Xing and handling demolition materials and conceived according to the highest technological standards for any types of materials in a reliable way, with constance and total safety.

Thanks to the interchangeable claws and the 360° hydraulic rotation it allows you to handle large loads and odd forms.

TECHNICAL FEATURES

MODEL MB-G1200
WEIGHT 1,65 Ton
LOAD CAPACITY (CLAWS CLOSED) 0,71 m³ / 710 L
ROTATION 360°
FLOW DIRECTION 20 - 35 l/min.
PRESSURE OF ROTATION > 220 bar
PRESSURE (OPEN/CLOSE) 300 - 400 bar
OIL FLOW (OPEN/CLOSE) 70 l/min.

The hydraulic flow and pressure must both meet the required parameters.
